Praher Plastics Butterfly Valve K4, PVC, flange connection, EPDM seal, A4 shaft, PN10, manually operated, grey

Butterfly valve K4 EPDM

• A4 stainless steel shaft
  for high corrosion resistance
• Flange connection
  for DIN, ANSI, JIS, BS
• Safety handle
  with label plate
• Can be automated
  via ISO 5211 interface

Description

The Praher Plastics butterfly valve K4, made of PVC-U, is a robust shut-off valve for swimming pool systems, water treatment, and industrial piping systems. Thanks to its flanged connection compatible with DIN, ANSI, JIS, and BS standards, it can be flexibly integrated into a wide variety of system configurations. The combination of PVC-U, an EPDM seal, and an A4 stainless steel shaft offers high corrosion resistance and is suitable for numerous applications in water technology.

The valve is rated for a pressure class of PN10 and can be automated using electric or pneumatic actuators via the ISO 5211 interface.

Product details

Features

• PVC-U construction for high corrosion resistance
• EPDM seal for water-related applications
• A4 stainless steel shaft for increased resistance to corrosive environments
• Flange connection for DIN, ANSI, JIS, and BS flange systems
• Double shaft seal to increase operational reliability
• Only the seal and valve disc come into contact with the medium
• Integrated mounting points for fixed-point installation
• Prepared for electric and pneumatic actuators
• ISO 5211 interface for easy automation
• Pressure rating PN10 for numerous water technology applications
• Safety handle with label plate (available in various colors)
• Metal insert to increase the strength and service life of the hand lever
• Radially installable and removable
• Flow direction-independent
• Full flow cross-section (nominal diameter)
• PPGFK snap-in plate with 10 locking positions

Technical data

Pressure - temperature - diagram

Torque at the shaft

Note: The values of the pressure-temperature-diagram are based on a service life of 25 years at static pressure load and apply to water or water-like media.

Flow rate - pressure loss

Flow characteristics

Kv-value table

Dimensions hand lever

Connector types flange (dimensions in mm)

Versions
