Compact filter system Bregenz 2
- Incl. filter pump
Smart EUROPRO - 6-way valve
included - Piping set
glued - Pre-assembled
on filter pallet
Description
Compact filter system consisting of polyester filter, self-priming filter pump and 6-way backwash valve. Completely piped and mounted on a noise-reducing PE filter pallet.
Product details
Polyester filter Bregenz 2
Filter container made of isophthalic resin, resistant glass fibres and UV-resistant gelcoat. The large transparent flange cover (d400 mm), the viewing window for the sand level and the large drain (1 ¼") make the filter particularly easy to inspect and maintain. 5-year guarantee on filter container tightness.
More infos
Filter container made of isophthalic resin, resistant glass fibres and UV-resistant gelcoat. The large transparent flange cover (d400 mm), the viewing window for the sand level and the large drain (1 ¼") make the filter particularly easy to inspect and maintain. 5-year guarantee on filter container tightness.
More infos
Smart filter pump EUROPRO
Self-priming, high-performance centrifugal pump with integrated pre-filter. Extremely quiet and very reliable. Developed for the circulation and filtration of water in private and public swimming pools.
More infos
Self-priming, high-performance centrifugal pump with integrated pre-filter. Extremely quiet and very reliable. Developed for the circulation and filtration of water in private and public swimming pools.
More infos
Original Praher 6-way valve
ABS housing, max. operating pressure: 3.5 bar, 7 positions including winter position, with glued piping set.
More infos
ABS housing, max. operating pressure: 3.5 bar, 7 positions including winter position, with glued piping set.
More infos
Dimensions
Swipe/scroll to see all columns
* (v = 50 m/h)
Dimensions Bregenz 2
Filling quantities
Swipe/scroll to see all columns
| d520 | d640 (1 ½") | d640 (2") | |
|---|---|---|---|
| Filter bed height (mm) | 480 | 504 | 504 |
| Nature Works (kg)* | 100 | 140 | 140 |
| Filter sand (kg)** | 100 | 150 | 150 |
* Filter glass, granulate size 0.6 - 1.2 mm | ** granulate size 0.4 - 0.8 mm
Scope of delivery
- Polyester filter Bregenz 2
- Smart filter pump EUROPRO, 50M or 75M
- Original Praher 6-way valve, 1 ½" or 2", black
- Valve pipework set, glued
- Ocean screw connections 3 pcs.
- Pre-assembled on PE filter pallet
FULLY AUTOMATIC FILTER CONTROL WITH AQUASTAR®
Manual pool filters of all common filter brands can be retrofitted with automation using our Aquastar® models and a suitable valve and piping set.
For filters including an original PraherPlastics 6-way valve, the installation of an Aquastar® drive is possible on request.
